Optimum Window works with architects who require custom designs for their applications, bringing performance and structural excellence together with beauty and style, to make every idea a reality through the use of new computerized machinery. All products are custom made per specifications and shop drawings.

AL / AR / LA / MS / TN
www.optimumwindow.com



Fire Rated Windows & Doors

FR4700

  • 45 minute fire rating
  • Solid Steel Sections
  • UL (Underwriters Laboratories) Listed and Certified
  • Fully Weather Stripped
  • 2 1/8″ exterior frame depth
  • Mitered and fully welded frame construction
  • Glazing is held in place via mechanically fastened steel glazing beads
  • Can accommodate glazing ranging from 3/16″ to ¾” in O.A. thickness
  • Insulated glazing available for this series
  • All FR4700 series casement windows will be factory glazed, unless ordered otherwise
  • 1 cam lock at center of sash up to 36″
  • Standard Optimum Window colors (refer to OWM color chart)
  • Units arrive with installation straps (upon request)
  • All units will receive Zinc Enriched Primer and Powder Coated finish

FR6000

  • 45 min rating
  • All Cold Rolled sections are formed from GALVANIZED STEEL
  • UL (Underwriters Laboratories) Listed and Certified
  • 1 7/8″ exterior frame depth
  • Frames are coped and mechanically assembled
  • Mitered, corner keyed frame and sash joinery
  • Glazing is held in place via mechanically fastened steel glazing beads
  • Can accommodate glazing ranging from 3/16″ to ¾” in O.A. thickness
  • Insulated glazing available for this series
  • All FR6000 windows will be factory glazed, unless ordered otherwise
  • Uniformed sight lines
  • Standard Optimum Window colors (refer to OWM color chart)
  • Units arrive with installation straps (upon request)

FR7650TDH

  • 45 min rating w/ Wire Glass
  • 90 min rating w/ Ceramic Glazing
  • All Cold Rolled sections are formed from GALVANIZED STEEL
  • UL (Underwriters Laboratories) Listed and Certified
  • EPDM and Silicone Pile Weather-Stripping
  • Frames are coped and mechanically assembled
  • 4 ¼” exterior frame depth
  • Glazing is held in place via mechanically fastened steel glazing beads
  • Can accommodate glazing ranging from 3/16″ to ¾” in O.A. thickness
  • Insulated glazing available for this series
  • All FR7650TDH windows will be factory glazed, unless ordered otherwise
  • 1 Sweep lock at center of sash up to 36″, two sweep locks thereafter
  • 2 Lift handles per lower sash
  • Balances are calibrated based upon sash weight
  • Standard Optimum Window colors (refer to OWM color chart)
  • Units arrive with installation straps (upon request)

FR8600

  • 45 min rating
  • All Cold Rolled sections are formed from GALVANIZED STEEL
  • UL (Underwriters Laboratories) Listed and Certified
  • EPDM and Silicone Pile Weather-Stripping
  • Mitered, corner keyed frame and sash joinery
  • 2 3/16″ exterior frame depth
  • Glazing is held in place via mechanically fastened steel glazing beads
  • Can accommodate glazing ranging from 3/16″ to 1″ in O.A. thickness
  • Insulated glazing available for this series
  • All FR8600 windows will be factory glazed, unless ordered otherwise
  • 1 cam lock at center of sash up to 36″, two sweep locks thereafter
  • Standard Optimum Window colors (refer to OWM color chart)
  • Units arrive with installation straps (upon request)

FR7650TSH

  • 45 min rating w/ Wire Glass
  • 90 min rating w/ Ceramic Glazing
  • All Cold Rolled sections are formed from GALVANIZED STEEL
  • UL (Underwriters Laboratories) Listed and Certified
  • EPDM and Silicone Pile Weather-Stripping
  • Frames are coped and mechanically assembled
  • 3 11/16″ exterior frame depth
  • Glazing is held in place via mechanically fastened steel glazing beads
  • Can accommodate glazing ranging from 3/16″ to ¾” in O.A. thickness
  • Insulated glazing available for this series
  • All FR7650TSH windows will be factory glazed, unless ordered otherwise
  • 1 Sweep lock at center of sash up to 36″, two sweep locks thereafter
  • 2 Lift handles per lower sash
  • Standard Optimum Window colors (refer to OWM color chart)
  • Units arrive with installation straps (upon request)

FR7600TSS

  • 45 minute fire rating
  • All Cold Rolled sections are formed from GALVANIZED STEEL
  • UL (Underwriters Laboratories) Listed and Certified
  • 4 ¼” exterior frame depth
  • EPDM and Silicone Pile Weather-Stripping
  • Frames are coped and mechanically assembled
  • Glazing is held in place via mechanically fastened steel glazing beads
  • Can accommodate glazing ranging from 3/16″ to ¾” in O.A. thickness
  • Insulated glazing available for this series
  • All FR7600TSS windows will be factory glazed, unless ordered otherwise
  • 1 Sweep lock at center of sash up to 36″, two sweep locks thereafter
  • 1 Self Latching handle
  • Standard Optimum Window colors (refer to OWM color chart)
  • Units arrive with installation straps (upon request)

FR55

  • 45 min rating w/ Wire Glass; 90 min rating w/ Ceramic Glazing
  • All Cold Rolled sections are formed from GALVANIZED STEEL
  • UL (Underwriters Laboratories) Listed and Certified
  • EPDM and Silicone Pile Weather-Stripping
  • 2 1/4″exterior frame depth
  • Glazing is held in place via mechanically fastened steel glazing beads
  • Can accommodate glazing ranging from 3/16″ to 3⁄4″ in O.A. thickness
  • Insulated glazing available for this series
  • All FR55 Fixed windows & doors will be factory glazed, unless ordered otherwise
  • Standard Optimum Window colors (refer to OWM color chart)
  • Units arrive with installation straps (upon request)
  • Fabricated in the United States of America

Door Features

  • Mitered, corner keyed fully welded frame and sash joinery
  • Doors will arrive with fire resistant hinges and door closer

Fixed Features

  • Mitered, corner keyed frame and sash joinery
